SZI Series Safety Light Curtain

SZI Series Safety Light Curtain we propose is well engineered by well-experienced professionals according to the global quality standards so as to offer great safety to the person from high functioning & automated dangerous machinery. It is ideal to install in area of production of various industrial sectors because of its outstanding safety offering attributes, less maintenance need and longer performance. Additionally, the SZI Series Safety Light Curtain is effortless to set up, economical, and is available in different varied models and specifications.

This is a SZI series Safety light curtain with no blind zone Safety grating and a 30*30mm cross-sectional area. This cost-effective SZ series safety light curtain can provide one-sided access protection and hazardous point protection, so that users can conveniently achieve safety protection from start to finish. This is the most practical solution that combines both, efficiency and safety. SZ series of safety light curtain is essential in industrial settings, as it guarantees the safety of people working there as well as machines and systems, for instance those used in processing machines of several sizes.

Technical Parameter:

• Section size: 30*30mm
• Protection grade: IP65
• Power: DC12V-36V +-10%
• Response time: less than 10ms
• Output: NPN/PNP/ Relay
• Sync type: Optical synchronization / Line synchronization
• Beam number: 4-500
• Accuracy: 10mm/15mm/20mm/40mm/60mm
• Protection height: 60-2000mm
• Protection distance: 0.1-1m,1-3m,1-5m,1-10m
• Anti-interference ability: 10000Lux
• Shape material: Aluminium alloy
• Circuit protection: Reverse protection / output short circuit protection
• Consumed power: 3-8W
• working temperature: -15-65 Centigrade
• ambient temperature: 20 Centigrade,RH less than 85%
• Product certification: CE ROHS



Model Selection Description:

Product selection needs to be selected from the following parameters, so as to form a complete product type and facilitate quotation.

• Protection height: (how many millimeters?)
• Minimum protection accuracy: choose one from 10mm,20mm, 40mm.
• Signal output: NPN, PNP, relay, MODBUS, 4-20mA, 0-10V, NPN two outputs, PNP two outputs.
• Signal output mode: NC (normal close contact), NO (normal open contact). (These two kinds of signal output mode are limited to NPN and PNP output mode.)
• The installation distance between the light transmitting terminal and the receiving end: (how many meters? )
